TL
A heavy-duty tube fiber laser cutting machine with four pneumatic chucks for processing large, long and heavy tubes.
- 6–20 kW Laser power
- 80–660 mm Round tube range
- 3,000 kg Single tube weight
- 4 chucks Clamping
Product description
The TL660 uses four heavy-duty pneumatic chucks to provide stable clamping for tubes weighing up to 3,000 kg and with round diameters up to 660 mm. Its automatic loading and unloading system supports heavy tube handling, while short-tailing and tube splicing functions support material utilization and downstream fabrication.
Features
Four-Chuck Heavy-Duty Structure
Four pneumatic chucks provide stable clamping for large and heavy tubes. The system supports round tubes with diameters of up to 660 mm and a single tube bearing capacity of 3,000 kg.
Short-Tailing Cutting
The four-chuck configuration enables reverse cutting for shorter tailings, helping improve material utilization.
Tube Splicing Technology
The TL supports more than 50 tube splicing patterns, including square tube, round tube, angle iron and channel steel applications, supporting subsequent welding operations.
HSG-X Bus CNC System
The 21.5-inch touchscreen provides a streamlined operating interface with real-time core component monitoring, early warnings, tube deviation detection and one-click processing reports.
Automatic Loading & Unloading
The automatic system handles heavy-duty tubes during loading and unloading, reducing manual handling and waiting time between operations.
Power-Off Cutting Restart
An absolute encoder-based servo system allows cutting to be restarted after a power failure with a single click.
Specifications
| Specification | TL660 |
|---|---|
| Power | 6kW–20kW |
| Weight of Single Tube | 3,000 kg |
| X/Y-Axis Positioning Accuracy | ±0.1 mm/m |
| Round Tube Cutting Capacity | 80–660 mm |
| Square Tube Cutting Capacity | 80 × 80–450 × 450 mm |
May we help?
- What is the maximum tube weight the TL660 can handle?
- The TL660 supports a single tube weighing up to 3,000 kg, making it suitable for heavy-duty tube processing.
- What tube sizes can the TL660 process?
- It can process round tubes from 80 mm to 660 mm in diameter and square tubes from 80 × 80 mm to 450 × 450 mm.
- How does the TL660 support downstream fabrication?
- Its tube splicing technology offers more than 50 splicing patterns, including options for square tubes, round tubes, angle iron and channel steel, helping prepare components for subsequent welding.
